Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck

Hubei Zhongzhong Huawei import and Export Co., Ltd
Contact Now

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck

Applicable Industries : Hotels, Farms, Restaurant

Showroom Location : Kenya

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2021

Warranty of core components : 1 Year

Core Components : Engine

Drive Wheel : 4X2

Fuel : Diesel

Transmission Type : Manual

Condition : New

Sprinkling Area (m) : 8 - 12m

Emission Standard : Euro 2

Engine Capacity : 4 - 6L

Dimensions (L x W x H) (mm) : 7800*2450*2850

Brand Name : howo

Place of Origin : Hubei, China

Gross Vehicle Weight : 5788

Warranty : 1 Year

Tank Volume : 5001 - 10000L

After-sales Service Provided : No overseas service provided

Product name : small city water bowser

Water tank truck type : Water Spraying Tank Truck

Name : water tank

Storage : Drinking Water

Drive type : 4x2 6X4 8x4

Pump : High Pressure Pump

Chassis brand : sinotruk

Color : CUSTOMER OPIONAL

After Warranty Service : Video technical support

Local Service Location : Philippines

Certification : CCC

Packaging Details : nude

Port : china port

Supply Ability : 200 Unit/Units per Month

Price : $22,400.00 - $26,400.00/Units

Contact Now

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck

Product details

Specification

(1) 4x2 water sprayer truck
(2) 2 Axle, single diff.

(3) Euro II emission.
(4) Horse Power 160HP
(5) Displacement: 4.257L

(6) water bowser type: Equipped with front/rear/side sprinkler
(7) Certification: ISO9001 CCC,SGS

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck

Technical parameters

Cabin

Driving type 4*2 LHD/RHD

Model ZZ

2080mm cabin, 1bed

Overall Size(mm) 7800*2500*2800
Tank Size(Liter) 2000L-8000L
Wheel base(mm) 4700
GVW(kg) 5700
Front axle loading capacity(kg) 1*3600
Rear axle loading capacity(kg) 1*10500
Engine Brand Yuchai
Model YC4E160-33
Type 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
Displacement 4.257L
Bore*Stroke 110*112mm
Hose Power(HP) 160HP
Emission standard Euro 2
Max speed 72km/h
Tire 9.00R20
Transmission WLY6T51 transmission, 6 forward and 1 reverse
Steering Power steering
Oil tank 220L
Brake system

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Electrics

Operating voltage:24V,negative grounded

Batteries:2x12 V,165 Ah horn,headlamps,fog lights,brake lights,indicators and reverse light

Options

Vertical Muffler;

ABS;

Automatic Break Clearance Adjusting Arm;

Traveling Data;

ZF Gearbox

PTO

ADR

Tank specification Equipped with front/rear/side sprinkler
Equipped with pump
Equipped with fire valve,water valve,and filter gauze

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck
Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck
Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truck
Our Services

Small water bowser sinotruk howo 4x2 water sprayer truck 2000L-10,000L water tanker truckWarranty

1. For Road truck:

One year quality guarantee for three key parts axles, engine, transmission or within

100000km, which comes the first.

For Off road truck & engineering truck:

Within 6 months or terminates 60,000 km, whichever is reached first.

Same timetable as to three key parts axles, chassis and land gear for road truck and off road truck seperately.

2. Other spare part could be supplied by OEM at cost prices.

3. Regularly callback to know the vehicle's working status.

4. The overseas engineers are always ready to deal with unexpected needs.

Maintenance

1.Check Check the oil pan, injection pump, oil bath air filter,oil in the power output gearbox, if the oil level rises regularly

2. Check the cooling water level in the tank, if the water is not enough,please add the water to the standard level. When the temperature is below + 5oC,the engine if off work,please discharge the water.(when there is no antifreeze fluid)

3. Check and tighten bolts and nuts out of the engine, excluding oil leaks, water leaks, air leaks.

4. When working in dusty places, remove dust on the air filter. And,replace the air filter when necessary.

5. Clear dirt , dust and oil on the surface of engine.

6. Listening to the voice when diesel engine is running, observing the color of exhausted air, exclude the problem and irregularities found.

7. Replace engine oil,clean oil pan and oil strainer,oil filter tank, repalce the oil in the injection pump, according detailed manual.

Our advantage

Factory

We have own factory and skilled worker, rich experienced design team and responsible QC and good after sales service

Quality and Price

Products Quality Certification SGS CCC ISO. And ensure high quality of your required products. Also we manage to control the cost and save every penny for your party.

Special

We can provide various kinds of special truck and trailer, various machinery for your choices. Also, we can customize per your specific requirements.

Experience

More than 20 years' experience as a manufacturer

Overseas branch
Oversea wareshouse with more than 100000 US dollors spare parts in stock, Oversea office with more than 15 professional engineers to help local customers
