Condition : New
Place of Origin : Hubei, China
Brand Name : SINOTRUK
Model Number : ZZ1317N3667C
Weight : 25000kg
Dimension(L*W*H) : 1140*2500*4000mm
Power : 371hp
Warranty : 6 Months
After-sales Service Provided : Overseas service center available
Certification : ISO CE
Engine : WD615.47
Color : Blue
Capacity : 16CBM
Type : Ready Mix Concrete Truck
Product name : Concrete Mixer Truck JCD-4
Chassis brand : Howo Sino Truck
Cab : HW76
Driving type : 6x4
Emission standard : Euro 2
Item : Concrete Mixing Machine
Packaging Details : Nude Pack. The packing shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.
Port : Shanghai and other
Supply Ability : 500 Unit/Units per Month
Price : $49,600.00 - $53,400.00/Units
16cbm howo 8x4 concrete mixer truck 12 wheels sinotruk big volume
Specification
(1) 8x4 concrete mixer truck
(2) 4 Axle
(3) Euro II emission.
(4) Horse Power 371HP
(5) Displacement: 9.726L
(6) Tank volume: 16CBM
(7) Certification: ISO9001 CCC,SGS
Technical Parameter
Cab | Driving type | 8*4 LHD RHD |
Model | ||
Bunk | HW76, 1bunk, AC | |
carriage size(mm) | 11400*2500*4000 | |
Wheel base(mm) | 1800+3600+1350 | |
GVW(kg) | 18220 | |
Engine | Brand | Sinotruk |
Model | WD615.47 | |
Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
displacement | 9.726L | |
Bore*Stroke | 126*130mm | |
Hose Power (HP) | 371 | |
Emission standard | Euro 2 | |
Max speed | 102km/h | |
Tire | 12.0-20, 12.00R20, 295/80R22.5, 12R22.5, 315/80R22.5 optional | |
Transmission | HW19710 transmission, 10 forward and 2 reverse | |
Front axle load capacity(kg) | 1*9000 | |
Rear axle load capacity(kg) | 2*16000 | |
Oil tank | 300L | |
Mixer Volume | 16CMB | |
Thickness | End plate | 6mm high tensile strength steel |
Mixer body | 5mm high tensile strength steel | |
Hydraulics | Motor,pump | Italian or American brand |
Gearbox | Italian brand | |
Brake system | Service brake:dual circuit compressed air brake | |
Parking brake (emergency brake): spring energy, compressed air operating on rear wheels | ||
Auxiliary brake:engine exhaust valve brake | ||
Electrics | Operating voltage:24V,negative grounded | |
Batteries:2x12 V,165 Ah | ||
horn,headlamps,fog lights,brake lights,indicators and reverse light | ||
Options | Vertical Muffler; ABS; Automatic Break Clearance Adjusting Arm; Traveling Data |
Warranty
1. For Road truck:One year quality guarantee for three key parts axles, engine, transmission or within
100000km, which comes the first.
For Off road truck & engineering truck: Within 6 months or terminates 60,000 km, whichever is reached first.
Same timetable as to three key parts axles, chassis and land gear for road truck and off road truck seperately.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.
Maintenance
1.Check Check the oil pan, injection pump, oil bath air filter,oil in the power output gearbox, if the oil level rises regularly
2. Check the cooling water level in the tank, if the water is not enough,please add the water to the standard level. When the temperature is below + 5oC,the engine if off work,please discharge the water.(when there is no antifreeze fluid)
3. Check and tighten bolts and nuts out of the engine, excluding oil leaks, water leaks, air leaks.
4. When working in dusty places, remove dust on the air filter. And,replace the air filter when necessary.
5. Clear dirt , dust and oil on the surface of engine.
6. Listening to the voice when diesel engine is running, observing the color of exhausted air, exclude the problem and irregularities found.
7. Replace engine oil,clean oil pan and oil strainer,oil filter tank, repalce the oil in the injection pump, according detailed manual.
Our advantage
Factory
We have own factory and skilled worker, rich experienced design team and responsible QC and good after sales service
Quality and Price
Products Quality Certification SGS CCC ISO. And ensure high quality of your required products. Also we manage to control the cost and save every penny for your party.
Special
We can provide various kinds of special truck and trailer, various machinery for your choices. Also, we can customize per your specific requirements.
Experience
More than 20 years' experience as a manufacturer
Overseas branch
Oversea wareshouse with more than 100000 US dollors spare parts in stock, Oversea office with more than 15 professional engineers to help local customers
![]() |
